Overview

The RRC family of LED Downlight retrofits is a highly efficient option for upgrading existing Incandescent, Fluorescent and Metal Halide downlight fixtures to energy saving LED. The highly efficient design allows users to capture energy savings while also gaining the benefit of dimming. Compatible with many architectural and commercial downlight housings this retrofit can be used in most downlight applications. Suitable for damp locations. Integrated EM option available.

Product Listing
Lighting Layout
Features
MaxLite Makes it!

Don't see what you need? Additional wattages and specifications available upon request - contact your MaxLite rep!

14
Battery Backup(14)
  1. 100351 Datasheet Quick View View More
    RRXC10U35Z
    9W3500K
    Lumens (lm):986Watts (W):9Equivalency:18W CFLCCT (K):3500Voltage (V):120-277Listings:Energy_StarClearance:No
    Lumens (lm):986Watts (W):9Equivalency:18W CFLCCT (K):3500Voltage (V):120-277Listings:Energy_StarClearance:No
    RRXC10U35Z 9W3500K
    100351
    View More
  2. 100645 Datasheet Quick View View More
    RRXC15U27Z
    13W2700K
    Lumens (lm):1251Watts (W):13Equivalency:26W CFLCCT (K):2700Voltage (V):120-277Listings:Energy_StarClearance:No
    Lumens (lm):1251Watts (W):13Equivalency:26W CFLCCT (K):2700Voltage (V):120-277Listings:Energy_StarClearance:No
    RRXC15U27Z 13W2700K
    100645
    View More
  3. 1410055 Datasheet Quick View View More
    RRXC15U30Z
    13W3000K
    Lumens (lm):1345Watts (W):13Equivalency:26W CFLCCT (K):3000Voltage (V):120-277Listings:Energy_StarClearance:No
    Lumens (lm):1345Watts (W):13Equivalency:26W CFLCCT (K):3000Voltage (V):120-277Listings:Energy_StarClearance:No
    RRXC15U30Z 13W3000K
    1410055
    View More
  4. 1410057 Datasheet Quick View View More
    RRXC15U40
    13W4000K
    Lumens (lm):1453Watts (W):13Equivalency:26W CFLCCT (K):4000Voltage (V):120Listings:Energy_StarClearance:No
    Lumens (lm):1453Watts (W):13Equivalency:26W CFLCCT (K):4000Voltage (V):120Listings:Energy_StarClearance:No
    RRXC15U40 13W4000K
    1410057
    View More
  5. 14099430 Datasheet Quick View View More
    RRXC20U27Z
    18W2700K
    Lumens (lm):1793Watts (W):18Equivalency:42W CFLCCT (K):2700Voltage (V):120-277Listings:Energy_StarClearance:No
    Lumens (lm):1793Watts (W):18Equivalency:42W CFLCCT (K):2700Voltage (V):120-277Listings:Energy_StarClearance:No
    RRXC20U27Z 18W2700K
    14099430
    View More
  6. 14099680 Datasheet Quick View View More
    RRXC20U35
    18W3500K
    Lumens (lm):2000Watts (W):18Equivalency:42W CFLCCT (K):3500Voltage (V):120Listings:Energy_StarClearance:No
    Lumens (lm):2000Watts (W):18Equivalency:42W CFLCCT (K):3500Voltage (V):120Listings:Energy_StarClearance:No
    RRXC20U35 18W3500K
    14099680
    View More
  7. 1410067 Datasheet Quick View View More
    RRXC20U40Z
    18W4000K
    Lumens (lm):2077Watts (W):18Equivalency:42W CFLCCT (K):4000Voltage (V):120-277Listings:Energy_StarClearance:No
    Lumens (lm):2077Watts (W):18Equivalency:42W CFLCCT (K):4000Voltage (V):120-277Listings:Energy_StarClearance:No
    RRXC20U40Z 18W4000K
    1410067
    View More
  8. 100369 Datasheet Quick View View More
    RRXC30U35Z
    29W3500K
    Lumens (lm):3150Watts (W):29Equivalency:2 x 42W CFLCCT (K):3500Voltage (V):120-277Listings:Energy_StarClearance:No
    Lumens (lm):3150Watts (W):29Equivalency:2 x 42W CFLCCT (K):3500Voltage (V):120-277Listings:Energy_StarClearance:No
    RRXC30U35Z 29W3500K
    100369
    View More
  9. 1410103 Datasheet Quick View View More
    RRXC30U40Z
    29W4000K
    Lumens (lm):3150Watts (W):29Equivalency:2 x 42W CFLCCT (K):4000Voltage (V):120-277Listings:Energy_StarClearance:No
    Lumens (lm):3150Watts (W):29Equivalency:2 x 42W CFLCCT (K):4000Voltage (V):120-277Listings:Energy_StarClearance:No
    RRXC30U40Z 29W4000K
    1410103
    View More
  10. 1410085 Datasheet Quick View View More
    RRXC50U40Z
    47W4000K
    Lumens (lm):4942Watts (W):47Equivalency:3 x 42W CFLCCT (K):4000Voltage (V):120-277Listings:Energy_StarClearance:No
    Lumens (lm):4942Watts (W):47Equivalency:3 x 42W CFLCCT (K):4000Voltage (V):120-277Listings:Energy_StarClearance:No
    RRXC50U40Z 47W4000K
    1410085
    View More
  11. 1410088 Datasheet Quick View View More
    RRXC50U50Z
    47W5000K
    Lumens (lm):4942Watts (W):47Equivalency:3 x 42W CFLCCT (K):5000Voltage (V):120-277Listings:Energy_StarClearance:No
    Lumens (lm):4942Watts (W):47Equivalency:3 x 42W CFLCCT (K):5000Voltage (V):120-277Listings:Energy_StarClearance:No
    RRXC50U50Z 47W5000K
    1410088
    View More
Product Filters
Lumens (lm)
Watts (W)
Equivalency
CCT (K)
Voltage (V)
Listings
Clearance
Add Options
Battery Backup
Utility Rebates

Choose a product from the dropdown menu below or type in your specific model number and then click on the interactive map to see what utility rebates are available for that product in that state.

Features
  • Mounts into existing recessed frame
  • Supplied with optional retaining clips if existing frame does not have adequate friction springs
  • cULus listed for damp location use
  • Universal voltage (120-277) (Triac 120V only)
  • 0-10V dimming and Triac dimming drivers available (select wattages)
  • A wide variety of CCTs available
  • Integrated EM option available (select wattages)
  • Type IC (excludes 50W)
Lighting layout
RRC Series Commercial Downlights Lighting Layout
